Pinouts Teensy 3.2 is meant to be a drop-in replacement for Teensy 3.0.

Pedvide's ADC library can be used to access both ADCs. For stereo audio or power monitoring, sampling both left and right, or voltage and current at the same moment is very beneficial. Teensy 3.2 has a second ADC, so you can concurrently measure 2 analog signals.

Two Analog to Digital Converters with analogRead(), you can measure many signals, but only 1 at a time.

The output is created by the stable reference voltage, so it's doesn't vary if your power supply voltage changes slightly.Simply use analogWrite() on the A14 pin for true analog output. You can always filter PWM, but true analog output responds rapidly.

12 Bit Analog Output Teensy 3.2 has a proper analog output.

Update: Color the color of Teensy 3.2 was changed from black to green on January 22, 2014. The green material has slightly higher resolution.

However, the analog-only pins (A10-A14), AREF, Program and Reset are 3.3V only. All digital pins are 5 volt tolerant on Teensy 3.2. These can now be directly connected to Teensy 3.1's digital inputs. 5 Volt Tolerance on Digital Inputs today most new chips use 3.3V signals, but many legacy products output 5 volt digital signals.Flash memory has also doubled, to 256K, and provides double the memory bandwidth.Icons and graphics for color displays and audio effects requiring delays, like reverb and chorus, will become possible on Teensy 3.2. While 16K is plenty for nearly all Arduino libraries, 64K allows for more advanced applications. The RAM has quadrupled, from 16K to 64K.

#Arduino sensors with teensy code

Teensy 3.2 has the same size, shape & pinout is compatible with code written for Teensy 3.0, and is well supported on the Arduino IDE using Teensyduino.mTeensy 3.2 adds several new features, due to an upgraded microcontroller.

#Arduino sensors with teensy Pc

No special programmer is needed, only a standard micro USB cable and a PC or Macintosh with a USB port. All programming is done via the USB port.

The Teensy is a complete USB-based microcontroller development system, in a very small footprint, capable of implementing many types of projects.
